The steerable transfer cart is an alternative transfer cart with the high capacity and quality, which has been popular product in material handling field.

Remark:BEFANBY can customize all kinds of material handling equipment such as rail transfer cart, trackless transfer cart, AGV, trailer, etc. You can click on the PRODUCT PAGE to view. Or CONTACT US!
Warranty: 2 Years
Capacity: 1-1,500 tons
Certificate: CE SGS ISO9001, SASO
Advantage: Peculiar set-up makes the transfer cart save cost and operate more conveniently
Product Description

The steerable transfer cart is an alternative transfer cart with the high capacity and quality, which has been popular product in material handling field. It not only overcomes many inconveniences of rail transfer carts and cranes due to limited working area, but dramatically reduce the material handling requirements of cranes and forklift while providing quick, safe and smooth movement of materials or objects through manufacturing facilities.

The steerable transfer carts can not only finish free-turning without the rail in the workshop, but also run on the straight line. Therefore, it does not affect traffic, does not hinder production, and the transfer cart is more flexible, the operation is more humanized. BEFANBY can make different type cart to meet client's requirements all over the world.

New Function:

1.The trackless transfer cart can realize go straight by a special device, other steerable transfer cart is difficult to realize it completely, which is our patent technical design.
2.Only one button control it to turning, otrher supplier can not realize it.
3.Smaller Turning Radius can realize by this design compared with other steerable transfer cart.
4. Save the cost more compared Previous design.

Main Feature:

1.Customized capacity from 1 ton to 1500 tons
2.Battery powered(Optional power source)
3.Robust Sturdy Frame
4.Omnidirectional: various steering on client request (normal, 90°, diagonal, 360° and many others)
5.Maintenance Free Battery and Intelligent Charger
6.Low battery alarm device. It will alarm, when the battery power is too low.
7.Any kind of wheels (polyurethane, vulkollan, solid, super elastic or pneumatic))
8.Anti-explosion, anti-high temperature, anti-water, anti-dust, etc
9.Customized system(lifting, weighing, titling, climbing, ferry, plc, etc.)
10. Optional Control System (Operation handle / Remote Controller / Cabin)
11.Safety System(LED flashing lights, Sound acoustic devices, E-stop, Dead man stop, Buffer, etc.)
12.Speed up to 10 Km/h
13.Well known components brand.

BEFANBY engineering team will always provide the optimal guiding method based on your site layout and requests to offer you the best product with the competitive price.





Parts
trackless transfer cart manufacturer



Remark: BEFANBY can customize all kinds of material handling equipment such as rail transfer cart, trackless transfer cart, AGV, trailer, etc. You can click on the PRODUCT PAGE to view. Or CONTACT US!

Product parameters
Technical Parameter of BWP Series Steerable Transfer Cart
Model BWP-2T BWP-5T BWP-10T BWP-15T BWP-20T BWP-25T BWP-30T BWP-40T BWP-50T BWP-60T BWP-70T BWP-80T BWP-100
Rated load(t) 2 5 10 15 20 25 30 40 50 60 70 80 100
Table Size Length(L) 2000 2200 2300 2400 2400 3500 3500 5000 5500 5600 6000 6500 6600
Width(W) 1500 2000 2000 2100 2200 2200 2200 2500 2600 2500 2600 2800 3000
Heigth(H) 450 500 550 600 600 700 700 800 800 850 900 950 1200
Wheel Base(mm) 1080 1650 1650 1600 1650 1650 1650 2000 2000 1800 1850 1950 2000
Axle Base(mm) 1380 1680 1700 1830 1850 2700 2700 3600 2850 2900 3500 3500 4000
Wheel Dia.(mm) Φ250 Φ300 Φ350 Φ400 Φ400 Φ450 Φ450 Φ500 Φ600 Φ600 Φ600 Φ600 Φ600
Wheel Quantity(pcs) 4 4 4 4 4 4 4 4 4 4 6 6 8
Ground Clearance(mm) 50 50 50 50 50 50 50 50 50 75 75 75 75
Running Speed(mm) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-18
Motor Power(kw) 2*1.2 2*1.5 2*2.2 2*3.5 2*4.5 2*5.5 2*5.5 2*6.3 2*7.5 2*10 2*12 30 40
Batter Capacity(Ah) 250 180 250 330 400 400 450 440 500 600 600 800 1000
Battery Voltage(V) 24 48 48 48 48 48 48 72 72 72 72 72 72
Running Time When Full Load 2.5 2.88 2.8 2.3 2.2 1.8 2 2.6 2.5 2.2 1.8 2 1.9
Running Distance for One Charge(Km) 3 3.5 3.4 2.8 2.7 2.2 2.4 3.2 3 2.7 2.2 2.4 2.3
Max Wheel load(KN) 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4 152 185 190
Reference Wight(t) 2.3 3.6 4.2 5.5 5.9 6.5 6.8 7.6 8 10.8 12.8 14.6 26.8
