Transfer Cart With Robot Arm
The Transfer cart with robot arm, it is used in assembly line for positional working. The PLC system are installed on the transfer cart to realized automated stop when move on a station.
- OEM: Support
- Vulnerable Parts: Give as gifts
- Warranty: 2 Years
- Delivery Time: 30-40 working days
The Transfer cart with robot arm, it is used in assembly line for positional working. The PLC system are installed on the transfer cart to realized automated stop when move on a station.
1.Support One-Stop Solution
2.Customized Solution On Request
3.Load Capacity reach to 1-1,500 tons can be customized on request.
4.Customized Power source
5. Safe bearing factor reach to 150%
6. All transfer cart with safety control system.
7. Stout steel frame.(adopt the box girder structure)
8. Free provide customized handling solution
9. Automated operation and transportation system are support
10. DC & AC motor supported
11. Support Installed on customers’ site
| Technical Parameter Of Transfer Cart With Robot Arm | ||
| Model | KPT | Remark |
| QTY | 1 SET | |
| Load Capacity (T) | 2.5 | Custom Capacity over 1,500T |
| Table Size (mm) | 1500(L)*1500(W)*400(H) | Box Girder Structure |
| Rail Inner Gauge (mm) | 1160 | |
| Power Supply | Mobile Cable Power | Dragged Chain to reduce the abrasion |
| Motor Power(KW) | 2.3 | |
| Motor | AC Motor | Support Frequency Charger |
| Running Speed(m/min) | 0-36 | Adjusted Speed |
| Running Distance(m) | 24.55 | |
| Wheel Dia.(mm) | 300 | ZG55 Material |
| Power | AC380V，50HZ | |
| Recommend Rail | P18 | |
| Color | Yellow | Customized Color |
| Operation Type | Hand Pendant + Remote Control+Touch Screen | |
| Special Function |
1. PLC Control(positionaI accuracy about 2.5mm) 2. Customized Table Structure to installed the robot arm |
|
