Transfer Cart for Battery Molten Salt Electrolysis
Transfer Cart for Battery Molten Salt Electrolysis
Transfer Cart for Battery Molten Salt Electrolysis
Transfer Cart for Battery Molten Salt Electrolysis
Transfer Cart for Battery Molten Salt Electrolysis
Transfer Cart for Battery Molten Salt Electrolysis
Transfer Cart for Battery Molten Salt Electrolysis
Transfer Cart for Battery Molten Salt Electrolysis
Transfer Cart for Battery Molten Salt Electrolysis

Transfer Cart for Battery Molten Salt Electrolysis

The transfer cart has been our patented product for molten salt electrolysis furnance fields, the whole cart consist of two sets, the one is placed in anode, the another is placed cathode, which use cooperatively.

OEM: Support
Vulnerable Parts: Give as gifts
Warranty: 2 years
Certificate: CE, SGS, ISO9001, SASO
Packing: The rail guided vehicle will be packed by the plastic film and tarp, the parts will be packed by the high quality wooden case.
Product Description

The transfer cart has been our patented product for molten salt electrolysis furnance fields, the whole cart consist of two sets, the one is placed in anode, the another is placed cathode, which use cooperatively.

Advantage

1. Support One-Stop Solution

2. Customized Solution On Request

3. Load Capacity reach to 1-1,500 tons can be customized on request.

4. Customized Power source

5. Safe bearing factor reach to 150%

6. All transfer cart with safety control system.

7. Stout steel frame.(adopt the box girder structure)

8. Free provide customized handling solution

9. Automated operation and transportation system are support

10. DC & AC motor supported



Product parameters
Transfer Cart for Battery molten Salt Electrolysis
Model KPT(anode) KPT(cathode) Remark
QTY 1 SET 1 SET
Application Workshop Workshop
Load Capacity (T) 2 1 Custom Capacity over 1,500T
Table Size (mm) 1800(L)*1500(W) 1600(L)*1500(W) Box Girder Structure
Lifting Height(mm) 2400 1900
Rail Gauge (mm) 1250
Power Supply Mobile Cable Power The dragged chain can be added to protect the cable
Motor Power(KW) 1.5
Motor AC Motor Frequency Charger Support
Running Speed(m/min) 0-10
Wheel Dia.(mm) 250  Casted steel Material
Power AC380V,50HZ
Running Distance(m) 10m
Recommend Rail  P12
Color Yellow Customized Color
Operation Type Hand Pendant + Remote Control
Special Design 1. Customized cart Structure
2. Customized hydraulic lifting system
